fischer Hinged pipe clamp FKS 25 - 30

Name: fischer Hinged pipe clamp FKS 25 - 30
Brand: fischer

Produkt varijante

Download of image data

Top Features

The rapid-locking mechanism allows for fast, time-saving installation.
Sound insulation insert.
Distance sleeves on the locking screw.
Loss protection of screw.

The one-piece hinged pipe clamp with quick-release fastener for plastic and metal composite pipes.

Advantages

The quick-release fastener allows a fast and time-saving installation.
The spacing sleeves on the locking screw stops over tightening of the pipes.
The tight fit of the sound insulation insert prevents it from falling out when inserting the pipe.
The compact construction of the hinged pipe clamp enables a simple post-installation insulation.
The screw's design stops it falling out during the installation.

The fischer plastic hinged pipe clamp FKS with rapid-locking mechanism allows for fast, time-saving installation of pipelines. The distance sleeves on the locking screw guarantee the gliding of the pipes with length expansions. Connecting nut with thread M 8 for holding threaded rods or hanger bolts. Pipe clamp screws with loss protection.

Properties

Material: steel DD11 (material no. 1.0332) acc. to DIN EN 10111
Zinc plating: electro zinc-plated
Connecting nut: resistance welded, M8, SW 13
Locking screw: flat head screw with combination recessed head
Material sound insulation insert:: NR/SBR/EPDM; chlorine-free; silicone-free
Sound insulation: for DIN 4109
Temperature range: -40 °C to +110 °C
Hardness: 60 ± 5° Shore A
Fire behaviour: DIN 4102: Class B2

Clamping range ( D )	25 - 30 mm
Max. recom. static load (centr. tension) ( N_rec )	0,8 kN
Thread ( A )	M8
Size	3/4 in
Height ( H )	44 mm
Width x thickness clamp band ( b x s )	20 x 1.25 mm
Height ( Z )	26 mm
Locking screw	M5
Amount	100 pcs
GTIN (EAN-Code)	4048962442557
