Stand-off installation TherMax 16

The approved stand-off installation with thermal separation in external thermal insulation composite systems

The fischer stand-off installation system TherMax 16 is a solution for thermally separated fixation in external thermal insulation composite systems (ETICS) and non-load-bearing layers with a thickness of between 62 mm and 290 m. In combination with the fischer injection mortars, the system is approved for fixations in concrete and masonry. The approval ensures added safety. The threaded rod has a glass-fibre-reinforced cone and cuts its own way through the plaster and into the insulation material without a setting tool. This saves time and money during the installation process. The fischer TherMax is steplessly adjustable when faced with uneven base materials. It is used to secure heavy loads like awnings, air conditioning units, and satellite antennas in concrete, aerated concrete, and masonry made from perforated and solid brick.

Opis proizvoda

Advantages
  • When combined with the injection mortars FIS EM Plus, FIS V, FIS SB and FIS Green, the stand-off installation is approved for high loads in a range of materials. This allows for a secure fixing.
  • Usable lengths of 62 to 290 mm can be covered with just one TherMax.
  • The plastic cone creates a thermal barrier between the fixture and the inner fixture, and offers an energy-optimised fixing.
  • The glass-fibre-reinforced plastic cone cuts its own way through the ETICS with a positive fit, and allows for a simple, fast and adjustable installation without the need for any special tools.

Dostupne verzije proizvoda


3 pronađeno verzija proizvoda

3 pronađeno verzija proizvoda

Verzija
DIBt-approval
Contents
Packaging
Amount
Broj artikla 051292

2 x TherMax M16,
2 x Sleeve 20 x 200,
1 x Bit,
1 x Cutting blade,
1x Extension hose,
1 x Sealing glue 80 ml,
1 x Manual

Folding box

2 [pcs.]

Broj artikla 051293

20 x TherMax M16,
20 x Sleeve 20 x 200,
5 x Bit,
5 x Cutting blade,
5 x Extension hose,
5 x Manual

Folding box

20 [pcs.]

Broj artikla 051543

10 x TherMax M16 R,
10 x Sleeve 20 x 200,
3 x Bit,
3 x Cutting blade,
3 x Extension hose,
3 x Manual

Folding box

10 [pcs.]

Legenda = Dopuštenje dostupno = Dopuštenje nije dostupno
Pregledano 3 od 3 verzija
0

Primjena i dozvola

Applications
For the thermally separated fixing of:
  • Awnings
  • Canopies
  • French balcony railings
  • Air conditioning units
  • Satellite dishes
Building materials
Approved for:
  • Concrete, cracked and non-cracked
  • Vertically perforated brick
  • Hollow blocks made from lightweight concrete
  • Perforated sand-lime brick
  • Solid sand-lime brick
  • Solid brick
  • Aerated concrete
* Detaljne informacije o građevinskom materijalu možete pronaći u registracijskom dokumentu.

Dozvola/dopuštenje

  • Z-21.8-1837
Za detalje pogledajte odgovarajuće dokumente

Uputa za sastavljanje

Functionality
  • The TherMax 16 is suitable for pre-positioned installation.
  • The self-tapping, glass-fibre-reinforced cone cuts its own way through the plaster into the insulation during installation.
  • The anti-cold cone uses a thermal barrier to minimise heat losses.
  • In the case of resistant plaster (e.g. thick cement plaster), it is recommended that the TherMax cutting blade included is used for grinding out the plaster.
  • The sealing of the annular gap with the adhesive and sealant Multi MS or KD or the construction adhesive sealant DKM seals the façade at plaster level.
Mounting Strip 1 Picture
Mounting Strip 1 Picture
Mounting Strip 1 Picture
Mounting Strip 1 Picture
Mounting Strip 1 Picture
Mounting Strip 1 Picture
Mounting Strip 1 Picture
Mounting Strip 1 Picture
Mounting Strip 1 Picture
Mounting Strip 1 Picture
Prikaži upute za sastavljanje u PDF-u

Dokumenti za preuzimanje

Odobrenja

Naslov Tip Kreirano Vrijedi do
DIBt, National German Certification (PDF, 1 MB) fischer Thermax to be used for anchoring stand-off constructions in concrete and masonry Z-21.8-1837 21. 1. 2022. 1. 12. 2026.
